11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

HONG KONG BESTWAY CO.LTD (SHENZHEN ALL-KEY TECHNOLOGY CO. LTD)
Contact Now
    Buy cheap 11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box from wholesalers

    Buy cheap 11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box from wholesalers
    • Buy cheap 11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box from wholesalers

    11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

    Ask Lasest Price
    Certification : CB , GS , CE , TUV, UL , CCC , FCC,PSE,KC,C-TICK
    Model Number : 11W KSAS010 Series
    Price : Negotiable
    Delivery Time : 35 days
    Payment Terms : T/T
    Supply Ability : 1Million/Month
    • Product Details
    • Company Profile

    11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

    11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

    Brand Name:•ktec
    Input:•Input Voltage: 90 to 264 VAC
    •Frequency : 47-50/60-63HZ
    •Input Current : 0.4A (Max) 100/240VAC
    •Inrush Current : 60A Max 100VAC at max Load
    100A Max 240VAC at max Load
    •Leakage Current: 0.25mA Max
    Output:•Over voltage protection
    •Over current protection
    at 110-250% of lo and Auto-recovery
    •Electronic short circuit protection
    •Operating temperature 0~40℃ Free convection
    •Operating humidity 10-90% RH Non Condensing
    •Sea level Non-operating temperature -20~ 80℃
    Safety standards:•Information technology equipment
    •IEC/EN 60950-1, UL 60950-1, CSA C22.2
    No. 60950-1-03, GB4943
    Certificates and approvals:•CB , GS , CE , TUV, UL , CCC , FCC,PSE,KC,C-TICK
    EMI Emission:•Radiation Test&Conduction Test:EN 55022/FCC Part 15
    •Harmonic Test: EN 61000-3-2
    •Flicker Test: EN 61000-3-3
    EMS immunity:•ESD Test:EN 61000-4-2
    •RS Test:EN 61000-4-3
    •EFT Test:EN 61000-4-4
    •Surge Test:EN 61000-4-5
    •CS Test:EN 61000-4-6
    •DIP Test:EN 61000-4-11
    Key Applications:Key Features of KSAS010 series
    •Light, extra slim, sleek, compact design
    •Green power, full complies with CEC level V, MEPS IV EUP2011
    •High power density
    •Extra safe design, have got their respective safety approvals
    •Completed protect function

    Key Applications of KSAS010 series
    •It’s suitable for an extremely wide range of applications, including:
    •Mobile Devices
    •ADSL
    •Pos
    •Audio & Video product
    •Set-top-box
    •Household appliance
    Payment Details:•Payment Terms: T/T,negotiable for OEMs
    Main Export Markets:• Eastern Europe
    • North America
    • Mid East/Africa
    • Central/South America
    • Asia
    • Western Europe
    • Australasia
